Film Slitting Machine TD-1000 For Barcode Ribbon
Jack Liu
Contact person
Basic Information
The slitter machine: Max 1000mm width (1) Model:TD-1000Ribbon taper Slitter(2) Application: SlittingJumboRolltorequestedwidthandlength; makingrollsandsticking leadingfilmforfinishedribbons.(3) MaximumdiameterforJumboroll: 650mm.(4) MaximumwidthforJumboroll:910mm.(5) CorediameterforJumboroll:6'(152.4mm) (6) Minimumwidthforslittedribbon:20mm. (7) Maximumdiameterforslittedribbon:100mm(for1'take up coreorbigger)(8) Diameterfortakeupcore:0.5', 1'(9) Take up cores at the same time: two cores allowed(10) Equipped cores: two cores allowed(11)Maximum Speedofslitting:100m/min. (Take up core should be 1)(12) Slitting thickness: 0.0045-0.016mm(13)Voltage: 3kw.(14) Leading film core: one(15) Leading film width: 300mm(16) Leading film thickness: ≤0.06mm(17) Max of Leading film out-diameter: 400mm(18) Machine Specification:lengthwidthheightweightpowervoltage3m1.8m1.8m2.5ton3-5kw380v
Delivery terms and packaging
Packaging Detail: in wooden pallet Delivery Detail: 2 months
Port: Shanghai
